Low Voltage Motors
Slip Ring Motors (LV)
CG has Low Voltage Slip Ring electric motors ranging from 3.7 kW to 350 kW in both TEFC (IP55) & Drip Proof (IP23) construction. These motors are designed with new Slip Ring and brush gear arrangement for trouble free operations and long lasting brush life , Slip Ring are moulded in epoxy-based insulation and excellent stability in operation at high temperature and have very good anti tracking property .
We also comply with IPSS standards to meet the requirements of Steel Plants.
Range
2.2 kW to 350 kW
Frame
IEC112 to 355 in cast iron
Mounting
Foot/Flange/Face
Pole
4 to 10 Pole (Other on request)
Frequency
50 or 60 Hz
Ambient
-40 to + 65 ° C other on request
Protection
IP 23/55
